Dongguan City Huatong Equipment Co. Ltd., rolling test machine, this machine is in conformity with the provisions of the standard requirements of the "UL817" element and the power cord cords general safety. Applicable to the production and quality inspection departments for power cord, DC line bending test. For wire, cable and a variety of products in a certain speed, angle and weight, frequency and other circumstances to detect the product's resistance to fold and performance, etc.
1, test station: 3, 3 work position synchronization
2, swing angle: around 180 degrees (adjustable), radius of cable test fixture can be assembled and disassembled conveniently
3, swing speed: 3-60 times /cpm digital display (adjustable)
4, counting function: 0 ~ 999999 (can be set)
5, 50, 100, load weight: 200, 300, 3 500g
6, the main function: each group were counted, automatic shutdown after breaking, automatically save the data, without manual care.
7 accessories: (1 copies of instructions within the six corners of the 1 sets of weights 15)
8, work power: AC220V, 50Hz, 5A
9, equipment volume: 900*600*850mm
